Truculence Configurations
TableTalkTM gives TruculenceTM the extraordinary ability to add, configure, adjust, reconfigure and upgrade onboard hardware. It can modify operation, add functions, add capability etc.
TruculenceTM Configuration Examples
Use your imagination and let the TabletalkTM tables do the talking. There is an extraordinary number of ways that Truculence can be configured to provide analytical solutions. Here are a few examples:
Stand Alone Smart Sensor (SASS)
A simple SASS configuration incorporating the Fireworks SS OEM FID module
- Communications to external system controller via UART or I2C
- On board Calibration and direct reporting in concentration
Basic Continuous Analyzer (THA)
The simplest self-contained continuous total hydrocarbon analyzer
- Fireworks DS module
- Mechanical control of flow
- external/independent temperature control
- System UI processor with wireless interface to smart device
Automated Continuous Analyzer (THA)
Total Hydrocarbon Analyzer
- Heated sampling manifold with Fireworks DS module-
- Mainyard Support PCB with Smart modules
- Temperature Control
- Flow Control
- I/O modules
- Auto calibration and Sample sequencing
- Full User Interface
Continuous Analyzer with Selective Catalytic Conversion (TNMHC)
Dual FID for real time determination of total non-methane hydrocarbons
- Dual FID for continuous measurement of THA and Methane
- Selective catalytic oxidation of hydrocarbons for methane measurement
- Real time reporting of total non-methane value
- Compact and price competitive
- Mainyard Support PCB with Smart modules
- Temperature Control
- Flow Control
- I/O modules
- Auto calibration and Sample sequencing
- Full User Interface
Abatement Efficiency Analyzer
Quad FID for dual TNMHC measurement
- Four FID instrument for real-time TNMHC of inlet and outlet of pollution abatement system
- Real time reporting of abatement system efficiency
- Compact and ultra-price competitive
- Mainyard Support PCB with Smart modules
- Temperature Control
- Flow Control
- I/O modules
- Auto calibration and Sample sequencing
- Full User Interface
Pseudo-CG Analyzer
Selective adsorption traps and flow switching
- Partially selective analysis at very low concentrations
- Selective adsorption Traps perform sample pre-concentration and release.
- Mainyard Support PCB with Smart modules
- Flash trap controllers
- Temperature Control
- Flow Control
- I/O modules
- Auto calibration and Sample sequencing
- Full User Interface
Traditional On-Line GC with Method Switching
Common process GCs can be easily configured
- Customized Selective GC analysis at low concentration
- Single or multi-detector configurations
- Simple or sophisticated automated column switching
- Mainyard Support PCB with Smart modules
- Temperature Control
- Flow Control
- I/O modules
- Auto calibration and Sample sequencing
- Method switching allows transition from continuous analysis to GC and back
- Full User Interface
Hybrid GC
Combination Flash trap and GC oven with sophisticated flow switching
- Incorporation of GC oven and flash traps
- traps can add selectivity to improve GC separations and also pre-concentration to reduce minimum detection limits.
- Customized Selective GC analysis at low concentration
- Single or multi-detector configurations
- Simple or sophisticated automated column switching
- Mainyard Support PCB with Smart modules
- Flash trap control
- Temperature Control
- Flow Control
- I/O modules
- Auto calibration and Sample sequencing
- Full User Interface
